TD-7420AS 2MP IR Bullet Camera
TD-7420AS 2MP IR Bullet Camera
The camera is suitable for the scenes which requires high definition image display such as finance, telecommunications, government, schools, shops, airports, factories and hotels and so on.
Description
The camera is suitable for the scenes which requires high definition image display such as finance, telecommunications, government, schools, shops, airports, factories and hotels and so on.
Introduction
Introduction
- 1080P real time image, high resolution, true color
- 4 kinds of standard and lossless high-definition video outputs
- Up to 1000 TVL resolution
- CMOS progressive scan, perfectly capture the moving object
- Support OSD menu
- High speed, long distance, real time transmission
- Auto color to B/W at low illumination
- Support ICR switch, true day/night
- Support noise reduction function
- 10-20m IR night view distance
- IP66 ingress protection
- Support COC
- Support 960H CVBS output
Specification
Specification
| Specifications | TD-7420AS(D/IR1) |
| Image Sensor | 1/3.6″CMOS |
| Resolution | 2M |
| Image Size | 1920×1080 |
| Video Output | AHD/TVI/CVI/CVBS |
| Image System | PAL/NTSC |
| Electronic Shutter | Auto;1/50s ~ 1/100000s(PAL);1/60s~1/100000s(NTSC) |
| IR Distance | 10-20m |
| Frame Rate | 30FPS(60Hz)，25FPS(50Hz) |
| Min. Illumination | 0lux（IR ON） |
| Lens | 3.6 mm ( 2.8 mm optional ) |
| Lens Mount | M12 |
| S / N Ratio | ≥52dB（AGC OFF） |
| Ingress Protection | IP66 |
| Function Control | OSD ( COC Control ) |
| Day & Night | ICR |
| Digital WDR | Yes |
| Digital NR | Yes |
| Global Exposure | Yes |
| Central Exposure | Yes |
| AGC | Yes |
| Auto White Balance | Yes |
| BLC | Yes |
| Front Light Compensation | Yes |
| Sharpness | Yes |
| Smart IR | Yes |
| Image Setting | Auto |
| Defect Correction | Yes |
| Language | Chinese/English |
| Angle Adjustment | Any angle |
| Others | |
| Power Supply | DC12V（±10%) |
| Power Consumption | Day：<65 mA；Night：<240 mA |
| Working Environment | -40℃ ~ 50℃，10% ~ 90% humidity |
| Dimensions ( mm ) | Ф65 x 147 |
